Name: Factory Supply Salt Stainless Steel 316L Optical Sorting Machine CCD Industry Color Sorter Salt Cleaning Separator High Precision China
Brand: Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd
SKU: WYCS5-320
Price: 7,250.00 USD
Availability: InStock

家 > 製品 > Wenyao色の選別機 >

Factory Supply Salt Stainless Steel 316L Optical Sorting Machine CCD Industry Color Sorter Salt Cleaning Separator High Precision China

Place of Origin:

China

ブランド名:

Wenyao

証明:

Model Number:

WYCS5-320

私達に連絡しなさい

引用を要求しなさい

プロダクト細部

Application:

Ore, Industrial Product, Tea, Dehydrated Vegetable, Grain, Peanut, Bean, Corn, Wheat, Rice

Channel Number:

320

Light Source:

LED

Machinery Function:

Shape Sorter, Color Sorter

Voltage:

220V`380V/50Hz

Filter:

SMC/CKD

Brand of Power Supply:

Taiwan Meanwell

Type:

CCD

Sorting Accuracy:

99.99%

CCD Sensor:

Toshiba

Type of Ejector:

Metal Ejector

Transport Package:

Plywood

支払及び船積みの言葉

Minimum Order Quantity

1 SETS

価格

USD 2000-12500 SETS

Packaging Details

PLYWOOD

Delivery Time

15 DAYS

Payment Terms

T/T, L/C

Supply Ability

500/YEARS

高精度コーヒーチェリー色ソートカフェ色ソート機カフェチェリー加工

最もよい価格を得なさい

ビデオ

ピーナッツ,ピスタチオ/ブドウのカラーソート

最もよい価格を得なさい

ビデオ

WENYAO 乾燥したアベリコットのための光学分類機

最もよい価格を得なさい

ビデオ

WENYAO 調整可能なパラメータ鉱山産業のための精細な分類鉱石色 Sorter

最もよい価格を得なさい

私達に連絡しなさい

+86--13855135585

service@wycolorsorter.com

+86-551-67699185

今接触

製品の説明

Product Description

Wenyao Color Sorter Machine

Wenyao Color Sorting Machine Function:
When color sorter is working, feed hopper in the materials under the action of vibrator is uniform distribution in each chute. The
CCD signal while the materials are dropping is in testing. If it is found that there are unqualified materials or impurities in
the materials, the ejector will blow the defective goods in the hopper.
* Focus On Systematic And Original Design
* Multi-Dimensional Intelligent Color Sorting
* Intelligent And Convenient Interactive Interface
* Make Color Sorting More Professional And Intelligent

Product Paramenters

Model	WYCS5-320
Channels	320
Output(kg/h) Depend on raw material impurity:	1300-2800
Sorting Accuracy(%):	≥99.9
Carryover Rate(bad:good):	≥10:1
Power Supply(KW):	2.9KW
Work Air Pressure(Mpa):	0.6-0.8
Air Consumption(L/min):	1300-2800
Voltage:	220V/50Hz
Weight(kg):	900
Diamension/Size (LWH)mm	22441540
Package:	Wooden Case

Main Components

FOCUS 1:

5400 linear CCD camera with high precision allows high definition identification and high speed sorting.
Most advanced ccd technology can sort materials accurately.
Toshiba CCD sensor
American process chip

FOCUS 2:

WenYao mechanical ejector with scientific design can make machine work stably for long time.
A new type of high frequency valve allows for low consumption of electricity , long life reaction speed, high durability, easy
maintenance, and improved color accuracy.

FOCUS 3:

Humanized touch panel, easy to learn, more that 15 kinds of language can choose,more convenient to operate.Concise touch panel
helps customer operate easily and promptly.
High quality FPGA processing technology, defects of 0.04mm2 can be detected.

FOCUS 4:

Configuration of the special LED light source allows for ten million kinds of color sorting with a fully adjustable
colourspectrum.
Materials can be sorted according to different configurations which is suitable for various sizes of sorting, no need to change
the light source.

FOCUS 5:

We adopt imported original SMC Filter which has high reputation in color sorter accessories market.

FOCUS 6:

Unique designed chutes ensure material flows constantly and smoothly by uniform manner.

FOCUS 7:

304 stainless steel.Rust protection; Wear-resisting,wearproof.

FOCUS 8:

WIFI Remote Device.Each machine is equipped with wireless devices to help customers achieve remote debug operations .

COMPANY PROFILE

ANHUI WENYAO Optoelectronic Technology Co., Ltd founded in 2007, which combined with design, manufacture and selling. We manufacture high-tech optical color sorter machine of sorting wheat, rice, tea, melon seeds, grains, coarse cereals, nuts, dried vegetables, dried seafood, plastics, ores, ect. Supply the service to customers from Asia, the Middle East European, South Africa and African markets.

Through countless cooperation and OEM service with international partners, ANHUI WENYAO has streamlined the proper procedures and processes and opened up professional techniques that are ahead of the color sorting field and delivered the highest-quality products to every corner of the world.

Through countless hardwork, we serve customers from all over the world. We have high reputation in domestic, Africa, Middle-East,South-East Asia market. Expect you to join our big family. We will never let you down.

What you can choose from wenyao?
---Over 15 years experiences focus on sorter machine.The biggest sorter machine factory.
---Advanced equipment, good quality
---Professional skills, all-related services
---High quality and efficiency technology
---Complete production line, quick delivery
---The biggest grain and oil machine manufacturer and exporter in China
---Exporting to more than 100 countries and regions

Customer Photos

Packaging&Shipping

Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Delivery Detail:
Within 15 - 20 days after received the 30% deposit.

FAQ

1. How To Use The Machine?
We Will Supply The Installation Instructions Or Video And Our Engineers Will Train Your Operators.

2. How Long About The Guarantee Period?
Years. And We Supply Lifelong Software Upgrade Services For Our Customers.

3. Can You Supply The Air Compressor, Air Tank And Air Filters?
Yes, We Can Provide Above Equipment, Our Standard Offer Includes Color Sorter Machine With Air Compressor, Air Tank And Filters.

4. Is Oversea Service Available?
Yes, Our Engineers Could Go Abroad When Required.
