Name: WENYAO CCD Camera AI Nut Color Sorter with Full Color Detection, Stable Operation and ≥99.99% Accuracy for Walnuts
Brand: Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd
SKU: WYB1
Price: 9250.00 USD
Availability: InStock

家 > 製品 > くだらない色の選別機 >

WENYAO CCD Camera AI Nut Color Sorter with Full Color Detection, Stable Operation and ≥99.99% Accuracy for Walnuts

CCD camera nut color sorter

walnut color sorting machine

AI nut sorter with warranty

起源の場所:

hefei china

ブランド名:

WENYAO

証明:

CE & ISO9001

モデル番号:

WYB1

私達に連絡しなさい

引用を要求しなさい

プロダクト細部

関数:

色の分類およびクリーニング

正確さ（%）:

99.99％以上

状態:

2022新しい

保証:

2年

応用:

穀物の種のナット

色:

注文/標準

カメラ:

東芝日本から

電圧:

220V 50HZ、220V 50HZ

支払及び船積みの言葉

最小注文数量

1個

価格

USD 9250.00/SET

パッケージの詳細

合板箱のパッケージのパッキングサイズ（L*W*H）:2.15*1.72*2.05M

受渡し時間

7-15仕事日

支払条件

L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム

供給の能力

1ヶ月あたり100個

+86--13855135585

service@wycolorsorter.com

+86-551-67699185

今接触

製品の説明

Product Description

WENYAO CCD Camera Nut Color Sorter for Walnuts with Full Color Detection and Stable Operation

Wenyao Color Sorting Machine Function:

Wenyao Nuts Color Sorter Machine, For peanuts. Groundnuts, Walnuts, Almonds, Hazelnuts, Pistachio nut Etc applications sorting Wenyao Nut Color Sorter is a powerful and intelligent machine that can sort various types of nuts such as pecans, hickory, macadamia nuts, almonds, and more. Our machine is equipped with innovative online detection technology that can detect and remove foreign material, shells, and products with blemishes, discoloration, loose pits, pit fragments, etc. We always strive to provide our customers with intelligent, professional, and comprehensive sorting solutions. With our advanced AI technology, we are confident that our color sorter machine is the perfect solution for businesses looking to increase efficiency and improve the quality of nut and dried fruit products.

MODEL(Technical Parameters)	WYB1
Channels	64
Output(kg/h) Depend on raw material impurity	400-1000
Sorting Accuracy(%)	≥99.9
Carryover Rate(bad:good)	≥13:1
Power Supply(KW)	1.5
Work Air Pressure(Mpa)	0.2-0.3
Air Consumption(L/min)	200-600
Voltage	180-240V/50Hz
Weight(kg)	550
Diamension/Size (LWH)mm	245010101539
Package	Wooden Case

* The data of the machine overall dimensions are for reference only, specific dimension will be subject to the installation drawing

Parts Detailed Photo

CCD Camera

*5340 linear CCD camera with high precision allows high definition identification and high speed sorting.

*Most advanced ccd technology can sort materials accurately.

*Toshiba CCD sensor

*American process chip

Self-developed Solenoid Valve

*WenYao mechanical ejector with scientific design can make machine work stably for long time.

*A new type of high frequency valve allows for low consumption of electricity , long life reaction speed, high durability, easy

maintenance, and improved color accuracy.

Adjustable LED Light Source

*Configuration of the special light source allows for ten million kinds of color sorting with a fully adjustable colourspectrum.

*Materials can be sorted according to different configurations which is suitable for various sizes of sorting, no need to change

the light source.

Intelligent computing integrated circuit

With unparalleled high performance and low abilityconsumption, the industry's highest Bandwidth andintegration, processing ability increased 5 times.

Humanized interface

*Humanized touch panel, easy to learn, more convenient to operate.Concise touch panel helps customer operate easily and promptly.*High quality FPGA processing technology, defects of 0.04mm2 can be detected.

Packing & Delivery

*Process visualization

From manufacturing to shipment, all processes can be supervised in real time according to your requirements.

And we welcome you to visit our factory in person.

In customer site

In Our Europe Customer Working Plant.

In Our Southeast Asia Customer Working Plant.



In Our South Asia Customer Working Plant.

Our Factory&Customer

ANHUI WENYAO Optoelectronic Technology Co., Ltd founded in 2007, which combined with design, manufacture and selling. We manufacture high-tech optical color sorter machine of sorting wheat, rice, tea, melon seeds, grains, coarse cereals, nuts, dried vegetables, dried seafood, plastics, ores, ect. Supply the service to customers from Asia, the Middle East European, South Africa and African markets.

Through countless cooperation and OEM service with international partners, ANHUI WENYAO has streamlined the proper procedures and processes and opened up professional techniques that are ahead of the color sorting field and delivered the highest-quality products to every corner of the world.

Through countless hardwork, we serve customers from all over the world. We have high reputation in domestic, Africa, Middle-East, South-East Asia market. Expect you to join our big family. We will never let you down.

FAQ

1. How to use the machine?

We will supply the Installation instructions or video and our engineers will train your operators.

2. How long about the guarantee period?
One year. And we supply lifelong software upgrade services for our customers.

3. Can you supply the air compressor, air tank and air filters?

Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.

4. Is oversea service available?
Yes, our engineers could go abroad when required.

5.How to calculate Installation personnel cost?

On condition that customer requires to install, our company would like to send 1 Engineer to guide for installation, then customer should to pay the cost, including transaction of Engineer's visa, transportation(air) for go abroad. and accommodation , local transportation and security when the Engineer arrived.
